The S 428 by Pursuit is the ultimate legend, offering unrivaled style, comfort, and power for fishing, cruising, and entertaining. Featuring quad Yamaha 425 XTO engines, it boasts the largest aft cockpit in its class with ample storage, fish boxes, and seating options. The spacious cabin is designed for maximum light and views, with innovative windows. From fishing to relaxing, this sport boat is packed with amenities like a beach platform, entertainment center, and convertible seating under the oversized hardtop. Get ready for your adventures with the S 428—where every detail exceeds expectations.

Key Features

2023 Pursuit S428 Loaded
Neptune gray hull with navy boot stripe
Quad 425XTO Yamahas with only 174HRS and extended warranty till 5/13/2030
Upgraded Fischer Panda 12 diesel generator
Seakeeper with upgraded platinum warranty (5 years/4000hrs/March 2028)
Siren Marine 12 zone boat monitoring system
Upgraded Gemlux bluewater outrigger bases and carbon fiber 22ft internal outriggers
Kahlenberg air horns
Upgraded mezzanine seat base (hydraulic actuator)
Flir thermal imaging camera
4 sided helm enclosure
Helm A/C and Heat
Bowthruster
Starke ceramic coating

Hull

• Pursuit® protection plan: 5 year hull and deck structural warranty; 5 year blister free warranty; 2 year limited warranty (through March 2025)
• Pursuit fresh white gelcoat and laminated hull with vinyl ester resin and engineered fabrics
• 5-Ply resin infused composite transom system with patented transom reinforcement grid
• Infused fiberglass structural grid system with molded finish and integrated bilge water management system
• Foam filled structural grid
• Bronze thru hull fittings below water line
• Chrome over bronze thru hull fittings below the 7-degree heel line
• Stainless clad composite thru hull fittings above the 7-degree heel line
• Bronze garboard drain
• Bow eye, 5/8" 316l stainless steel
• Integrated transom platform extensions outboard of engines
• Boarding ladder, 3-step telescopic, mounted in hull platform
• Molded hull side frameless tempered glass windows
• Anchor system, integrally molded thru stem
• Forward hull compartmentation with one (1) 900 GPH bilge pump with automatic float switch
• Two (2) 1500 gph bilge pumps with electric switches
• Lewmar Bow thruster, 5.4 hp (4.0kw) with dedicated group 31 AGM battery, switch and fuse
• Blue bottom paint

Deck

• Hull and deck joint: mechanically fastened and thru bolted at cleat locations
• Rub rail: high density PVC with solid 316l stainless steel insert
• Transom cap, 316l stainless steel
• Molded one piece deck and cockpit liner with non-skid pattern area and overboard drains
• Cleats, 316 stainless steel, 10" pop up (2) stern, (4) spring and (2) bow
• Molded recessed hatches with gaskets and 316l stainless steel latches and overboard drain tracks
• Flush mounted integral anchor locker with fiberglass lid including vertical anchor windlass with switch at helm and remote at anchor locker, 316l stainless steel through stem anchor roller with 8" mooring cleat, chain binder, 35lb stainless steel plow style anchor, self-righting swivel, 320' rode (5/8" 8 plait including 20' of G4 chain), fresh and raw water quick connect fittings and a led courtesy light
• Self-draining cockpit with molded water management and 316l stainless steel drainage grates
• Bow to mid-ship grab rails, 316l stainless steel (port and starboard)
• Transom grab rails, 316l stainless steel (port and starboard)
• Single level splash well deck with non-skid for athwartship access
• Shore power inlet, 316l stainless steel
• Dockside freshwater inlet

Cockpit

• Molded forward bow seating with insulated storage below, electric actuating hinged forward facing backrests for port and starboard seats with clear passage forward (removable jump seat)
• Bow tables (fiberglass) with removable bases and designated storage
• Bow sunpad chaise for two (2) with adjustable backrests, armrests and drink holders
• Forward facing seating with adjustable backrest for two (2) forward of chaise
• Bow floor access hatch with dedicated gear locker/storage below deck (access to bow thruster components)
• Custom cockpit upholstery with dri-fast foam and mesh backing
• Full cockpit breathable coaming bolsters with dri-fast foam
• Pursuit custom triple captain’s seats with dedicated folding armrests, three (3) articulating flip-up bolsters and lumbar support, center seat has fore, aft and vertical adjustments
• Helm seat box content: slide-out trash can access (port side) dc panel and battery switch access (starboard side)
• Bridge/helm machinery access hatch
• Molded cockpit entertainment center with Corian accents, molded sink, hot/cold mixing faucet, electric cockpit grill, top load refrigerator/freezer (11 gallon) with digitally controlled thermostat, sliding storage tray, hinged fiberglass lids, cutting board, dedicated storage drawers and 120v outlet with GFI protection
• Aft facing molded mezzanine seat with armrests and dedicated storage below and secondary row of forward-facing bridge seats (2) (entire assembly is power sliding fore/aft with new style hydraulic actuator)
• Custom molded cockpit table with dedicated storage
• Folding transom seat with patent-pending flipping backrest
• Extra deep drink holders, 316l stainless steel, eleven (11)
• Cockpit machinery access hatch
• Fresh water cockpit shower with hot/cold mixing valve and pull-out sprayer
• Raw and freshwater outlets in cockpit with quick connect fittings and 25' coil hose
• Yamaha automatic electronic engine flush hose connection
• Side boarding door, inward opening (port side)
• Side boarding door swim/dive ladder receiver
• Side boarding platform, outward opening, electrically actuated (starboard side) with swim/dive ladder receiver
• LED cockpit courtesy lights (10) with waterproof switch in cockpit
• LED mid-level cockpit accent lights (10), full spectrum, with control panel
• Cockpit fire extinguisher under gunwale
• Stamoid covers for all seating areas

Fishing Features

• Rod holders, ten (12) total, stainless steel
• Four (4) in gunwale, four (4) in transom
• Four (4) in bow
• Transom live wells, lighted Oceana blue (36 gallons each) recirculating and insulated with fiberglass lid and acrylic window (port and starboard)
• Cockpit tackle center with storage for four (4) plano trays and tackle drawer (port and starboard)
• Fish boxes, three (3) totaling 134 gallons
• Transom (68 gallon) insulated, refrigerator/freezer with digitally controlled thermostat and overboard drain
• Cockpit floor (42 gallon) insulated, diaphragm pump with overboard discharge (port)
• Cockpit floor (24 gallon) insulated, diaphragm pump with overboard discharge (starboard)
• Rod storage, lockable, under port gunwale for three (3) with custom embroidered reel pad
• Rod storage, under bow gunwale for two (2) with custom embroidered reel pad (port and starboard)
• Rod storage, under hardtop for two (2) (port and starboard)
• Rod storage, lockable, in cabin for four (4)
• Aluminum reinforcement plates and wiring for downrigger installation, aft gunwale (port and starboard)
• Upgraded Gemlux bluewater outrigger bases and internal carbon fiber outriggers

Hardtop and Windshield

• Molded fiberglass full beam hardtop with visor
• Underside of hardtop is Neptune Gray
• Integrated SS electric retractable sunshade for aft seating areas
• Powder coated hardtop structural supports integrated ladder rungs for access to hardtop
• Custom windshield system with optically clear laminated windshield glass with electrically actuated vents (port and starboard), tempered side glass with powder coated structural frame and grab rails, 316l stainless steel (port and starboard)
• Pantograph windshield wiper with freshwater washer
• Anchor/stern led lights with burgee rings and USA flag with electrically actuated mount
• External AM/FM antenna with electrically actuated mount
• Six (6) tri color LED lights
• Two (2) aft facing spreader lights, one (1) forward facing spreader light
• Integrated stereo speakers, four (4)
• Rod storage, under hardtop for two (2) (port and starboard)
• Fiberglass hardtop with dedicated radar, antenna, outrigger locations and grab rails, 316L stainless steel (port, starboard and aftwartship)
• Hardtop access/ventilation sliding hatches (port and starboard) with integrated ladder
• Horn, upgraded Kahlenberg
• Navigation lights, LED, 2-mile

Helm

• Molded fiberglass aft tilting helm with instrumentation visor, electronics mounting surface, fold out fiberglass footrest/platform and safety lanyard
• 12v switch panel with illuminated rocker switches and backlit function
• Steering wheel, 316l stainless steel, with control knob and non-slip grip on Yamaha electric steering control with programable steering friction
• Custom helm accents with upholstery and blue LED lighting
• Top load glovebox (contains JL Audio USB port and wireless phone charger)
• Custom grab rail, 316l stainless steel
• Bow thruster joystick control
• Single windshield wiper with washer control
• Ritchie® navigator compass
• Port fold-down footrest
• Zipwake trim system control panel
• 240V 16,000 BTU A/C and heat with high volume blower.  Vents behind seats
• Jl Audio media master full function display
• Helm drink holders (2) extra deep and (2) regular, 316l stainless steel
• 12v outlets (1) and dual USB charger (1)
• Helm fire extinguisher under gunwale
• Yamaha® Command Link plus display
• Helm mechanical space access hatch with nonskid and synthetic teak accents

Cabin

• Molded acrylic access door with secondary framed screen door and 316l stainless steel locking latch
• Full fiberglass cabin deck liner
• Full fiberglass hull liner with sound dampening insulation
• Cabin entry steps with custom handrail and wood treads
• Custom solid wood tongue and groove floor accents
• Solid wood veneers on interior cabinetry
• Solid wood interior table with fixed table leg, 316l stainless steel
• Hanging locker
• 240v/60 Cycle cabin air conditioning w/reverse cycle heat, 8,000 BTU
• 32" LED TV with custom cabinetry surround
• Forward berth with 5" foam cushions and filler
• Removable settee backrests with outboard storage and indirect accent lighting (port and starboard)
• Vista View forward console side windows (port and starboard) allow sightlines through hull side windows
• Aft console side windows (port and starboard) with integrated flush portlights
• Custom window trim with accordion style blinds
• Interior rod storage, head bulkhead (2) and starboard side (2)
• Overhead skylight with custom upholstered accent
• 12v outlet. one (1), dual USB charger, three (3)
• Companionway switch panel
• Accent floor lights, two (2)
• Overhead led at companionway, one (1)
• Overhead led at berth, four (4)
• Indirect strip lighting, three (3)
• Storage drawer with integrated prep surface
• 120v microwave oven (1.1 cu. Ft.)
• Coffee Maker
• 120v outlet with GFI protection
• Co monitor
• Fire extinguisher
• AC distribution panel

Head

• Fiberglass private head compartment with non-skid pattern area
• Corian® countertop with sink, hot/cold faucet and storage cabinet below
• Vacuum flush elongated marine head with 22 gallon holding tank, macerator discharge pump, 316l stainless steel deck pump-out fitting and bronze thru hull fitting with seacock
• Fiberglass toilet seat cover
• Upper vanity mirror
• Toilet tissue holder
• Towel rack
• Shower sump box drain with automatic discharge pump
• Shower with Hot/Cold Mixing Valve and Shower Wand
• Tempered glass console side window with vented portlight and privacy screen
• 120V outlet with GFI protection
• Two-switch panel with overhead led lights, three (3) and floor LED accent light two (2)
• Head door gear hook
• Shower curtain with storage cover

Electrical

• UL® rated fully tinned, color-coded copper wire
• Custom in-house built, heat sealed, mechanically crimped, color-coded battery cables
• Custom in-house built, electrical harness with waterproof connectors and chafe protection
• Powder coated, aluminum, screen printed (front and back) battery switch and breaker panel
• Bonding system: thru hull fittings below water line, zinc anode and garboard drain
• Eight battery system: port engine (1), port center engine (1), starboard center engine (1), starboard engine (1), electronics (1) (AGM), house (2) (AGM) and bow thruster (1) (AGM)
• One (1) 40-amp battery charger for house, electronics and bow thruster batteries
• One (1) 20-amp battery charger for engine batteries
• 12V outlets, two (2) and dual USB chargers, four (4)
• One grounding bus bar
• Single 240V 50-amp 60 cycle dockside power connection
• 240V 50 amp 50’ Dockside power cord with switch or wireless remote operated electric cord retract reel
• Isolation transformer
• 120V outlets with GFI protection, three (3)
• Pursuit custom 12V and 120V interior MDP switch panel for cabin interior circuits

Mechanical

Aft Mechanical Space

• Seakeeper 6 gyro stabilizer: includes comprehensive structural integration, Seakeeper factory certified installation with platinum warranty (5 years/4000hrs)
• Upgraded Fischer Panda 12 diesel generator
• Generator hours: 190 (Oct 2024)
• Automatic fire suppression system
• Molded interior white gel coat
• Molded hatch with gasket and stainless steel gas spring
• Molded bilge sump area
• Mechanical space access steps (port and starboard)
• One (1) 1500 GPH bilge pump with electronic switch and one (1) 1500 GPH pump with high water electronic switch and alarm with stainless steel-clad composite thru hull fittings
• Raw water pump with inline filter, seacock and thru hull fitting
• Livewell cyclone pump with bronze sea strainer, seacock and thru hull fitting (port and starboard)
• Dedicated fish box diaphragm evacuation pumps
• Dedicated storage for side door/platform boarding dive style telescoping ladder
• Dedicated storage for 12 lb. fluke style anchor with 30' of 1/2" 8-plait line and poly storage rack
• Dedicated storage for 5-gallon bucket
• Battery service slide system, 316L SS (port and starboard)

Fwd Mechanical Space

• One low profile 900 GPH bilge pump with integrated float switch, with stainless steel-clad composite thru hull fitting
• Fresh water pressure sensing pump with filter

Fuel

• EPA compliant 574-gallon aluminum fuel tank with engine pickups, shutoff valves, digital level indicator, and deck fuel fill plate (port side)
• Custom built premium fuel feed lines with mechanically crimped fittings
• Four (4) Yamaha® water separating fuel filters with primer bulbs
• EPA Compliant Lined 24 Gallon Rotomolded Diesel Fuel Tank with Engine Pickup, Shutoff Valves, Digital Level Indicator, Water Separating Fuel Filter and 316L Stainless Steel Deck Fill Plate

Water

• 35 Gallon water tanks (2) with single point level indicator and 316l stainless steel deck fill plate (starboard side)
• Premium Sea Tech color coded water hose system with mechanically crimped ends
• Pressure sensing/variable speed pump
• Fresh water distribution manifold with dedicated valves
• Dockside freshwater inlet with pressure regulator
• 6 Gallon stainless steel water heater, 240v/60 cycle

Electronics

• Garmin® Electronics Package: Dual GPSMAP 8622 [1 XSV], Airmar B175M 20 Degree 1KW CHIRP Transducer, GMS 10 Expander, GSD25 Sounder Module, Yamaha MFDI Interface, Pursuit Custom Dash Panel, VHF Radio
• Garmin GMR 54 open array radar
• Garmin GC-14 rear facing camera
• Sirius XM weather receiver
• Pursuit cockpit JL audio custom tuned entertainment System: JL Media Master 12V Bluetooth® compatible stereo system, premium JL Audio speakers eight (8) total, six (6) 7.7" exterior and two (2) 10" subwoofers, two (2) amplifiers, remote at bow
• Upgraded JL Audio M6 Sport Speaker package
• Zipwake trim control system, series s interceptors, fully automatic pitch and roll control
• Siren Marine 12 zone boat monitoring system, cellular/gps connections
• FLIR camera
• Yamaha setpoint autopilot
• 6 Seablaze X2 spectrum all color underwater lights

Disclaimer

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
